MT5705
-
產(chǎn)品概述
MT5705 is a SoC based wireless power receiver which is designed for applications with up to 5W power delivery and can be configured as a wireless charging transmitter to provide power to other receivers. It is fully compliant with WPC Qi specification (Version 1.2.4). The AC input can be converted to fully programmable DC output voltage due to the magnetic induction charging technology. Designed with ARM Cortex M0 processor, integrated with optimized and adaptive full synchronous rectifier control and special LDO, the chip achieves high efficiency, ultra-low bias current and very small power MOSFET RDSON.
MT5705 is embedded with various protection features, such as FOD, over-voltage, over-current and over-temperature protection which guarantee the system reliability.
-
產(chǎn)品特性
Power delivery: up to 5W
Fully programmable output voltage and current limit
Embedded with ARM Cortex M0 processor with 2KB SRAM and 8KB OTP
AC input to DC output efficiency: up to 95%
Embedded with various protection features:over-voltage, over-current, overtemperature protection, FOD
Innovative output LDO with output clamping and fast response to line and load transient
Qi version 1.2.4 compliant and proprietary communication protocols support with hardware ASK modulation
Independent I2C slave interface with additional GPIO’s
Halogen free and RoHS compliant
4.00mm x 4.00mm QFN32 package
-
Smartphones and wearable devices with high integration and small form factor
-
Rx function for power banks where they can be wirelessly charged
-
Other wireless power applications
