MT7606S
-
DESCRIPTION
MT7606S is a high current precision linear LED driver. The output constant current is programmable by an external resistor.
MT7606S integrates high voltage power MOSFET and high voltage power supply circuit, which simplifies the peripheral circuit. It can easily pass EMI without inductor, transformer or other magnetic components, low BOM cost is achieved.
The chip integrates thermal regulation function to balance the output power and system temperature. The output current will be reduced while the junction temperature goes higher than the threshold, system reliability is guaranteed.
-
FEATURES
Few external components, low BOM cost
Integrated with 500V power MOSFET
LED current set by external resistor
Constant current precision: ±5%
Low EMI interference
Embedded with thermal regulation function
Available in SOT89-3 and ESOP8 package
-
LED candle, Filament lamp
-
LED fluorescent, panel light
-
LED Bulb, Projection lamp
-
Other compact LED lightings
